T-Motor MN6007 II Multirotor VTOL UAV Motor KV160

TM-1113-5200
Hover on image to enlarge
Sourced to Order
12.750,37 ₺ + VAT 15.300,64 ₺ VAT included Estimated deliveryUsually 9–25 business days
Ask a question

Minimum quantity for "T-Motor MN6007 II Multirotor VTOL UAV Motor KV160" is 1.

This is not local warehouse stock; it is sourced to order after a supplier availability check.

50% deposit, 50% on delivery

Pay 50% of the product price as a deposit when placing your order. We source the product for you, and you pay the remaining 50% when you receive it.

Total including VAT
15.300,64 ₺
Deposit at order (50%)
7.650,32 ₺
Balance on delivery (50%)
7.650,32 ₺

This payment breakdown is based on the displayed price of one item.

T-Motor MN6007 II Multirotor VTOL UAV Motor KV160 is part of the T-Motor mn antigravity type uav motors range. This listing covers the model and configuration identified below.

DroneStore Benefits

No Full Payment Before Delivery

Pay 50% when ordering and the remaining 50% upon delivery.

Earn 1 TRY in Reward Points per 100 TRY

Earn reward points with your purchases.

Fast, Hassle-Free Shipping

Careful packaging and planned shipping. Estimated delivery: 9–25 business days.

Payment Options up to 9 Installments

Contact us for available payment options.

2-Year Warranty

We are here to support you after your purchase.

Sourcing Tailored to Your Needs

Contact us for the products and parts you need.

Description

T-Motor MN6007 II Multirotor VTOL UAV Motor KV160 is part of the T-Motor mn antigravity type uav motors range. This listing covers the model and configuration identified below.

Product and configuration details

BrandT-Motor
ModelMN6007 II Multirotor VTOL UAV Motor KV160
ConfigurationKV160
Manufacturer product codeT-MOTOR001113
DroneStore product codeTM-1113-5200

Manufacturer technical tables

The tables below contain manufacturer model and product-family data. Check the model and configuration identified in each table; filterable values for the selected product appear under Technical specifications.

Motor SizeΦ67.2*26.1mm
LeadEnameled Wire 70mm
StatorAnti-rust treatment; 180℃ high temperature-resisting coatings
Copper Wire220℃ high temperature resistance: Level C
Configuration24N28P
Coil Insulation Test500V
Shaft DiameterIN:6 OUT:4
Rotor Dynamic Balance Standard≤15mg
BearingImported 696ZZ
Packing Size122*99*45.5mm
Magnet Level150℃ high temperature resistance: Level E
KV160
Internal Resistance178mΩ
Idle Current（18V）0.5A
Rated Voltage(Lipo)12S
Peak Current（180s）23.7A
Motor Weight（Incl. Cable）159g
Max. Power（180s）1120W
Package Weight180g

Manufacturer product details

T-Motor MN6007 II Multirotor VTOL UAV Motor KV160 — Manufacturer product details 1T-Motor MN6007 II Multirotor VTOL UAV Motor KV160 — Manufacturer product details 2T-Motor MN6007 II Multirotor VTOL UAV Motor KV160 — Manufacturer product details 3T-Motor MN6007 II Multirotor VTOL UAV Motor KV160 — Manufacturer product details 4T-Motor MN6007 II Multirotor VTOL UAV Motor KV160 — Manufacturer product details 5

Technical drawings and performance charts

T-Motor MN6007 II Multirotor VTOL UAV Motor KV160 — Technical drawings and performance charts 1T-Motor MN6007 II Multirotor VTOL UAV Motor KV160 — Technical drawings and performance charts 2
Features
Brand:
T-Motor

Technical specifications

Product type:
Motor
Motor KV rating:
160 KV
Compatible LiPo cell count:
  • 12S
